Festo SMEO-1-S-LED-24-B Proximity Sensor SMEO-1-S-LED-24-B Block Design

The proximity sensor, also known as a proximity switch, initiator, or non-contact switch, with type number SMEO-1-S-LED-24-B from Festo is an electrical sensor in block design for contactless detection of metallic objects. It features a Reed switching element function (normally open contact), is bipolar, and designed for connection to a NAMUR interface. An integrated LED status indicator and an M8x1, 3-pin connector are additional features. The device has dimensions 2 x 2 x 4 cm and weighs 0.021 kg. Proximity sensors are used for precise position monitoring of components in machines and systems, as well as for end-position sensing in pneumatic or hydraulic cylinders. Typical applications include automation technology, mechanical engineering, and conveying systems for object detection and counting.

Proximity sensor with Reed switching element function (normally open contact), bipolar, for connection to a NAMUR interface. Features LED status indicator and M8x1, 3-pin connector.
