Festo VUVG-L14-M52-MT-G18-1R8L Solenoid Valve

The pneumatic solenoid valve from Festo, also known as a switching valve, control air valve, or electromagnetic valve, with type number VUVG-L14-M52-MT-G18-1R8L, is an electrically controlled component for the precise control of compressed air in pneumatic systems. It features IP65 protection and is supplied with a socket. The nominal width is 5.6 mm. The sealing principle is soft, and the mounting position is arbitrary. The exhaust function is throttleable. For manual operation, a detenting, concealed, and momentary manual override is available. It is a pilot-operated valve with internal pilot air supply and positive overlap. The control pressure range is between 3 and 8 bar, and it is not suitable for vacuum. The switch-on time is 13 ms and the switch-off time is 40 ms. It has the dimensions 15 x 5 x 5 cm and weighs 0.1 kg. Solenoid valves are typically used in automation technology, mechanical engineering, and robotics to switch media flows via electrical signals, thereby automating and controlling processes.

Schutzart IP65 mit Steckdose Nennweite [mm] 5,6 Abluftfunktion drosselbar Dichtprinzip weich Einbaulage beliebig Handhilfsbetätigung rastend verdeckt tastend Steuerart vorgesteuert Steuerluftversorgung intern Überdeckung positive Überdeckung Steuerdruck [bar] 3 bis 8 Vakuumtauglichkeit nein Schaltzeit aus [ms] 40 Schaltzeit ein [ms] 13
