Festo 161760 Pressure Switch G1/4 IP65 Wechsler

The pressure switch, also known as pressure sensor, manostat or pressure transducer, with type number 161760 from Festo is a pneumatic-electric sensor for monitoring and controlling pressure. It features an adjustment scale and has dimensions of 2 x 5.5 x 3 cm as well as a weight of 0.175 kg. The device complies with standard EN 60947-5-1 and is suitable for relative pressure measurement. Pressure switches convert physical pressure into electrical signals and serve to monitor pressure levels in pneumatic systems, triggering an electrical switching signal when a predefined pressure is reached or exceeded. Typical applications include controlling valves and cylinders in industrial automation, and safeguarding and monitoring critical pressure ranges in tanks and pipelines in process engineering.

Pneumatic-electric pressure transducer with adjustment scale. Complies with EN 60947-5-1. Suitable for relative pressure measurement.
