Aventics R422100968 5/2-Way Valve TC08 Series 24VDC

The 5/2-way valve of the TC08 Series from Aventics, also known as a pneumatic solenoid valve, directional valve, or control valve, with type number R422100968, is an electrically actuated component in pneumatics. It operates with a supply voltage of 24VDC, is externally piloted, soft-sealing, and blockable. The valve is suitable for plate or pipe connection. It has the dimensions 4 x 13 x 2 cm and weighs 0.165 kg. 5/2-way valves are used to control the flow direction of compressed air in pneumatic systems by switching between two output ports, thereby regulating the movement of actuators. Typical applications include automation technology for actuating double-acting cylinders in machinery and systems, as well as in process control for regulating media flows.

5/2-way valve, TC08 series, 24VDC, external pilot, soft sealing, blockable. Suitable for plate or pipe connection.
