Valeo 403.957 Gear Motor 24V

The 24V gear motor, also known as a reduction gear motor or geared motor, is an electrical gear motor. It is a brushless DC motor with a worm gear from Valeo, bearing the OEM part number 403.957. It has dimensions of 12 x 9 x 20 cm and weighs 1.2 kg. Gear motors are essential components that efficiently convert electrical energy into mechanical rotational energy. They enable precise control of speed and torque, especially in applications that require high torque at low speed, thus optimizing motion control. Typical applications include use in drive systems for automation technology, in conveying technology for material transport, and in precise positioning systems for robotics.

Brushless DC motor with worm gear. Nominal voltage 24V. Nominal speed 67 rpm. Nominal torque 5 Nm. Peak torque 25 Nm. Gear ratio 63:1. Protection class IP40. Weight 1.2 kg.
