Heidelberg L4.014.010 Dowel screw

The dowel screw, also known as a shoulder screw, guide bolt, or positioning screw, is a screw for mechanical applications. It serves the precise positioning and connection of machine parts and ensures exact alignment as well as the prevention of relative movements. It has the dimensions 5 x 5 x 10 cm and weighs 0.02 kg. The part number L4.014.010 comes from the manufacturer Heidelberg. Dowel screws find typical applications in precision mechanical engineering, in the assembly of components where exact alignment is critical, and in tool and fixture manufacturing. The spare part is compatible, among others, with the machines 'Heidelberg CD 102', 'Heidelberg XL 105', 'Heidelberg CD 74' and 'Heidelberg SM 102'.

VIM 12.9
