Festo VFOF-LE-BAH-G18-Q6 One-Way Flow Control Valve QS-6 G1/8

The one-way flow control valve, also known as a throttle check valve, exhaust air throttle, or flow regulator, with the type number VFOF-LE-BAH-G18-Q6 from Festo, is a pneumatic valve for regulating the airflow in one direction. It is specifically designed for controlling exhaust air and features a QS-6 pneumatic connection (port 1) and a G1/8 pneumatic connection (port 2). It has dimensions of 7 x 1 x 4 cm and weighs 0.1 kg. The one-way flow control valve operates within an operating pressure range of 0.2 to 10 bar. Such valves are used to precisely control exhaust air flows in pneumatic systems, thereby regulating the movement speeds of cylinders. Typical applications are found in automation technology, mechanical engineering, and handling systems, where unidirectional speed control of actuators is required.

One-way flow control valve for exhaust air with QS-6 pneumatic connection (port 1) and G1/8 pneumatic connection (port 2). Operating pressure range from 0.2 to 10 bar.
