Festo ADVU-50-60-A-P-A Compact Cylinder 50mm Bore 60mm Stroke Elastomeric Dampening

The double-acting pneumatic compact cylinder from Festo, also known as short-stroke cylinder, small-format cylinder, or compact working cylinder, with type number ADVU-50-60-A-P-A, is a component for precise movements in automated systems. It features a bore of 50 mm and a stroke of 60 mm. The device is equipped with elastomeric damping rings at both ends, which ensures gentle end-position cushioning. It has the dimensions 7 x 7 x 13 cm and weighs 0.95 kg. The compact cylinder operates with an operating pressure range of 0.8 to 10 bar. Compressed air according to ISO 8573-1:2010 serves as the medium. It is suitable for proximity sensors. Typical applications are found in handling technology, for positioning workpieces, or in assembly automation, where minimal installation space and precise movements are required.

Double-acting compact cylinder with a 50mm bore and 60mm stroke, featuring elastomeric damping at both ends. Designed for precise movements in automated systems. Suitable for proximity sensors. Operating pressure range is 0.8 to 10 bar. Medium: Compressed air according to ISO 8573-1:2010.
