Festo 19231 Standard Cylinder DSNU 16mm Bore 80mm Stroke PPV Double-Acting Pneumatic

The standard cylinder, also known as pneumatic cylinder, compressed air cylinder, or working cylinder, with type number 19231 from the DSNU series by Festo, is a pneumatic cylinder for converting compressed air energy into mechanical linear motion. It features a bore of 16 mm and a stroke of 80 mm. The double-acting function enables both extension and retraction of the piston by compressed air. Adjustable pneumatic cushioning (PPV) on both sides ensures smooth end positions and reduces wear. The cylinder conforms to the ISO 6432 standard. It has the dimensions 3 x 2.5 x 18 cm and weighs 0.125 kg. Pneumatic cylinders are typically used in automation technology, mechanical engineering, and material handling, for instance, for clamping, positioning, or transporting workpieces and materials. They find application in packaging machines, assembly lines, and conveyor systems.

Pneumatic standard cylinder, DSNU series, with 16mm bore and 80mm stroke. Features double-acting function and adjustable pneumatic cushioning on both sides (PPV). Conforms to ISO 6432 standard.
