Festo 19194 Standard Pneumatic Cylinder DSNU-12-100-P-A

The standard pneumatic cylinder, also known as pneumatic cylinder, air cylinder, or actuator, with type number 19194 from Festo is a standard pneumatic cylinder. It has dimensions of 3 x 3 x 21 cm and weighs 0.16 kg. With a bore of 12 mm and a stroke of 100 mm, it is designed for a maximum operating pressure of 10 bar. The device has a round cylindrical design and is equipped with position sensing via a proximity sensor. Elastomer end-position cushioning ensures smooth movements. Pneumatic cylinders convert the energy of compressed air into linear motion and are used to perform work tasks in machines and systems. Typical applications are found in automation technology, mechanical engineering, packaging machines, as well as assembly and handling systems.

Standard pneumatic cylinder with a bore size of 12mm and a stroke of 100mm. Designed for a maximum operating pressure of 10 bar. Features a round cylindrical shape and is equipped with position sensing via proximity sensor. Has elastomer end-stroke damping.
