Baumer IFRM 08P37A1/S35L Sensor Baumer IFRM 08P37A1/S35L

The inductive proximity sensor from Baumer, also known as proximity switch, inductive switch or non-contact switch, with type number IFRM 08P37A1/S35L, is an electrical sensor for non-contact object detection. It features a cylindrical threaded housing made of stainless steel with a diameter of 8 mm and an active face made of PBT. The sensor offers a nominal sensing distance of 2 mm and is designed for flush mounting. It operates with a supply voltage of 6-36 VDC and has a PNP NC output with an output current of 200 mA. The device is protected against short circuits and reverse polarity and is IP67 rated for dust and water resistance. Connectivity is ensured via an M8 connector and the operating temperature is between -25 and +75 °C. It has dimensions 10 x 10 x 5 cm and weighs 0.02 kg. Inductive proximity sensors are used for reliable, non-contact detection of metallic objects in industrial applications, without mechanical wear. Typical applications include position detection in automation technology, end position sensing in machine controls, and speed monitoring on conveyor systems and packaging machines.

Inductive proximity switch with a cylindrical threaded housing made of stainless steel, measuring 8mm in diameter. Features a sensing face made of PBT, a 2 mm nominal sensing distance, and is designed for flush mounting. It operates with a voltage supply range of 6-36 VDC and has a PNP NC output circuit with a 200 mA output current. Protected against short circuits and reverse polarity. Rated IP67 for protection against dust and water. Includes an M8 connector for connectivity. Suitable for operating temperatures from -25 to +75 °C.
